INTERACTIVE DECK EXAMPLE

A little more room.
A whole new perspective.

Change a dimension. Look underneath. See how the deck, stairs and house fit together.

LIVE 3D DESIGN STUDY01 / RESIDENTIAL DECK

A deck, drawn from dimensions.

Loading the interactive study…

MAKE IT YOUR OWN

Try a different proportion.

Main width feet · 30–42 Main depth feet · 10–16 Deck height inches · 24–48 Board finish illustrative colors

Look closer House context Dimension labels Reveal schematic framing

36′ × 12′ main deck · 2′ stepped return · 40″ assumed height

Reference dimensions — height and stair geometry still need field verification.

JavaScript is needed for interactive 3D. Reference: 36-foot width, 12-foot main depth, a 2-foot stepped return and approximately 40-inch height. Read the planning notes below.

Residential deck exampleIllustrative design · Not a permit drawing

EXPLORE THE DESIGN

Find your proportions.

Adjust the width, depth, height and board finish. Switch views to explore the stairs and framing.

Choose Reset reference to return to the original example. Changes reset when you reload the page.

BEFORE YOU BUILD

An example, not a building plan.

The house, ground and framing are illustrative. This model does not check structural sizes, connections or code compliance.

Your project needs verified site measurements and a design suited to local requirements.

LOCAL PERMIT RESOURCES

Find your next step.

Visit the Cincinnati permit hub for official city, county and township resources. Custom design and permit-plan services are coming soon.

DECK DESIGNS & PERMITS / COMING SOON

There’s more to come.

Designs & permits
